H170 Chipset 9th I3 I5 I7 Industrial Mini Computer With 8 Gigabit LAN 4 Ports 10G SFP Fiber

Basic Information
Place of Origin: China
Brand Name: VEGASHINE / OEM
Model Number: BF10208041R-H170
Minimum Order Quantity: 1 unit
Packaging Details: Carton
Delivery Time: 3 to 10 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000 units per Month
Chassis: 1U Chassis Galvanized Steel Sheet Chassis Dimension: 440mm*250mm*44mm
Chassis Color: Black Chipset: Intel® H170
CPU: Support Intel® 6/7/8/9th Core® I3/i5/i7 Memory: 2* DDR4
Gigabit LAN: 8* Intel® I211 Glan SFP: 4*Intel XL 710-BM2 10G Fiber Interface
COM Port: 1* CISCO Standard Serial Port Power Supply: AC 110V ~ 240V ATX Redundant Power Supply
Highlight:

I3 Industrial Mini Computer

,

I5 Industrial Mini Computer

,

8LAN I7 Mini Computer

8 Gigabit LAN 4 ports 10G SFP fiber optical H170 chipset support 9th I3 I5 I7 Industrial computer firewall PC appliance soft router support pFsense with redundant power supply



Key Features

Support LGA1151 Intel® 6/7/8/9th Core® i3/i5/i7 processor

Adopt Intel® H170 high speed chipset

Support 2* DDR4 memory slot max up to 64GB

Integrated Intel® HD Graphics

1*HDMI

Support 1*2.5" / 1*3.5’ HDD bay

Support 1*MSATA SSD expansion

8* LAN (Intel i211, 1000/100/10Mbps)

4*Intel XL 710-BM2 10G fiber interface SFP

1* CISCO standard serial port

2* USB3.0

AC 110V ~ 240V ATX redundant power supply

Dimension : 440mm*250mm*44mm

High quality galvanized steel sheet chassis

1U standard rack mounting method



Specifications

Model No.
  BF10208041R-H170
Chassis Color Black
Dimension 440mm*250mm*44mm
Structure 1U Standard chassis
Material High quality galvanized steel sheet
Installation 1U standard rack mounting method
Platform Processor Support LGA1151 Gen 6/7/8/9th Intel® Core® i3/i5/i7 processor
Chipset Adopt Intel® H170 high speed chipset
Graphics

Integrated Intel® HD Graphics

support 1*HDMI display output

Storage Memory 2* DDR4 memory slot, support 2133/2400/2666MHz, max up to 64GB
HDD Support 1*2.5" / 1*3.5’ HDD bay (3*SATA3.0 interface)
SSD Support 1*MSATA SSD expansion
Audio Audio N/A
Network Ethernet

8* LAN (Intel i211, 1000/100/10Mbps)

4*Intel XL 710-BM2 10G fiber interface SFP

WiFi /4G 1*Mini PCIe support WIFI / 4G modules (For optional)
Front I /O Serial Port 1* CISCO standard serial port console
USB 2* USB3.0
LAN 8* RJ45 Gigabit Ethernet Port
LED 1* HDD LED, 1* Power LED
Back I/O Display 1*HDMI
Power Switch 1*Power switch
Power Supply 1* ATX Power Interface
Power Supply Input AC 110V ~ 240V
Type ATX redundant power supply
Reliability Operating Temp. 0℃~45℃
Storage Temp. -20℃~70℃
Relative Humidity 5%-95%, no condensing
Vibration 0.5g rms/5-500HZ/random/operating
Operate System Support Win 7/8/10, Linux, Pfsense, Mikrotik, iKuai, WayOS, LEDE, Openwrt, Panabit, Smart6 , Ubuntu , Centos etc.







About RMA

1--Warranty 1 year

2--If buyer confirm the item can`t work well due to the non-artificial factors,buyer can return it to our company. Buyers should keep it with proper packaging.

3--Buyers are responsible for return to china freight cost .

4--Seller will repair item and ship the repaired one to buyer,seller will pay the shipping cost from China to Buyer address.

5--Please contact us firstly before returning defective goods by email.



Shipping



Support DHL / UPS / FEDEX / air shipping deliver time 4 to 9 business days

Support Sea shipping for Batch order deliver time 25 to 50 days
