| Place of Origin: | Shenzhen China |
|---|---|
| Brand Name: | VEGASHINE / OEM |
| Model Number: | EC-E6242C-12 |
| Minimum Order Quantity: | 1 unit |
| Packaging Details: | Carton |
| Delivery Time: | 3 to 10 work days |
| Payment Terms: | T/T, Western Union, |
| Supply Ability: | 1000 units per Month |
| CPU: | Support Intel Alder Lake 12th Gen CPU | RAM: | 1*NB-DDR4 Memory Slot |
|---|---|---|---|
| Ethernet: | 2*Gigabit LAN | Display: | LVDS/eDP+eDP+2HDMI |
| COM: | 6*COM | Power: | Supports 12V~24V Wide Voltage Power Supply |
| USB: | 2 * USB3.2 Gen1 (5Gbps), 6 * USB2.0 | Size: | 146mm(L)*102mm(W)*26mm |
Key features
Support Intel Alder Lake 12th gen CPU
Support 1*NB-DDR4 memory slot, supports 2133/2400/2666/2933/3200 memory, maximum support 32GB
2*HDMI 2.0, 1*EDP1 pin, 1*LVDS/EDP2 pin
1/2*RJ45 LAN
1*M2-WIFI interface
1*NGFF interface support for NVME protocol and SATA protocol
1*SATA1 interface
2*USB3.2 , 6*USB2.0 interface
6* COM ports
supports 12V~24V wide voltage power supply by default
Size: 146mm(L)*102mm(W)*26mm
Specifications
| Model No | EC-E6242C-12 | |
| Size | 146mm(L)*102mm(W)*26mm | |
| CPU | Support Intel Alder Lake 12th gen CPU | |
| Memory | 1*NB-DDR4 memory slot, supports 2133/2400/2666/2933/3200 memory, maximum support 32GB | |
| Power supply | 1*DC_IN or | The inner diameter of the DC head is 2.5mm, and the motherboard supports 12V~24V wide voltage power supply by default |
| 1*ATX (4Pin) | The maximum turbo power consumption of the U series CPU is 55W, and it is recommended to use a 12V 7A or higher power supply; | |
| The maximum turbo power consumption of the P series CPU is 64W, and it is recommended to use a 12V 7A or higher power supply; | ||
| The maximum turbo power consumption of the H series CPU is 115W, and it is recommended to use a 12V 10A or higher power supply; | ||
| Display | Support single display, dual display/triple display/quad display replication, dual display/triple display/quad display expansion, dual display under SHELL; | |
| 2*HDMI 2.0 | 4K resolution 4096/3840*2160@60Hz | |
| 1*Type_C | Display, USB data transfer, and power supply function | |
| 1*EDP1 pin | EDP-C screen cable, 4K resolution 4096/3840*2160@60Hz | |
| 1*LVDS/EDP2 pin | 1920* 1080@60Hz | |
| Network | 1/2*RJ45 LAN | Support network wake-up and PXE diskless boot function |
| 1*M2-WIFI interface | PCIE3.0 signal and Key-E interface M.2 2230 WiFi BT module | |
| Hard disk | 1*NGFF interface | PCIE4.0 signal, Key-M interface M.2 2280 hard drive, default support for NVME protocol and SATA protocol |
| 1*SATA1 interface | Standard SATA 3.0 hard drive interface | |
| Sound | Default support for Realtek ALC897 HD digital audio decoder and 6-channel high fidelity audio controller | |
| USB | 2*USB3.2 interface | |
| 6/4*USB2.0 interface | ||
| Other I/O | 1*COM1 pin | |
| 1*COM2 pin | ||
| 1*COM3-6 pin | ||
| 1*CLR_CMOS pin | ||
| 1*J_GPIO pin | ||
| BIOS | AMI BIOS,Support power-on boot, timing boot, remote switch machine intelligent identification | |
| Operating system | Win11,Win10,Linux | |
| Model | CPU | 4K | COM | LAN | USB2.0 | USB3.0 | Type-C | Memory | SSD | Power |
| EC-E6242C-12 | Intel Alder Lake 12th gen U/P/H i3,i5,i7,i9 | 4K 60Hz | 6 | 1 | 6 | 2 | 1 | 1*NB-DDR4 | 1*M.2 | 12~24V wide voltage |
| 6 | 2 | 4 | 2 | 1 | MAX 32G | 1*SATA |
