| Place of Origin: | Shenzhen China |
|---|---|
| Brand Name: | VEGASHINE / OEM |
| Model Number: | FW-BB44-1090NP-J41 |
| Minimum Order Quantity: | 1 unit |
| Packaging Details: | Carton |
| Delivery Time: | 3 to 10 work days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 units per Month |
| CPU: | Celeron J4125 Processor Quad-core, 2.00GHz | RAM: | 2 X DDR4 Up To 8GB |
|---|---|---|---|
| Display: | 1 X DP , 1* HDMI | Ethernet: | 4*INTEL® I226 2.5G |
| USB: | 2*USB3.0, 2*USB3.0 | Size: | 120 X 120 Mm |
| Power: | DC12V | COM: | 1*RJ45 COM |
Intel® quad cores J4125 NANO Motherboard 4*2.5G LAN firewall pc motherboard
Key features
Onboard Intel® Celeron J4125 Processor Quad-core 2.0GHz
2 x DDR4 2400 slots up to 8GB
1 x SATA interface
1 x M-SATA SSD interface
1 x M2_2280 SSD interface (PCIE2.0 X1)
Onboard INTEL 4* I226 2.5G LAN ports
1 x DP , 1* HDMI
2 x USB 3.0 interface
2 x USB 2.0 interface
1*RJ45 COM port
4 x RJ45 LAN interfaces
DC_12V single power input
120mm x 120mm
Specifications
| CPU | Onboard Intel® Celeron J4125 Processor Quad-core, 2.00GHz base frequency, 4MB Cache, TDP 10W |
| Memory | 2 x DDR4 260PIN SO-DIMM slots (supports 1.2V memory) |
| Memory Type: DDR4 2400 | |
| Maximum Memory Support: 8GB | |
| Storage | 1 x SATA interface |
| 1 x M-SATA SSD interface | |
| 1 x M2_2280 SSD interface (PCIE2.0 X1) | |
| Expansion Bus | 1 x MINI PCI-E interface |
| Network | Onboard INTEL® I226 2.5G network chip, 4 LAN ports |
| Front I/O | 1 x DP , 1* HDMI |
| 2 x USB 3.0 interface | |
| 1 x PWR_ON | |
| 2 x USB 2.0 interface | |
| Rear I/O | 1 x PWR_LED |
| 1*RJ45 COM port | |
| 1 x DC_IN power interface | |
| 4 x RJ45 LAN interfaces | |
| Builtin Interface | 1 x SATA power interface |
| 1 x 7pin SATA interface | |
| 1 x JCOM pin header (optional 1 x RS232 or 1 x RS485) | |
| 1 x JGPIO interface (supports 8-channel input/output GPIO) | |
| 1 x Front panel interface | |
| 1 x CPU fan power socket | |
| 1 x SIM card slot | |
| Power Type | DC_12V single power input |
| Working Temp. | -20℃~55℃ |
| Storage Temp. | -20℃~70℃ |
| Working Humidity | 5%-90% relative humidity, non-condensing |
| Dimension | 120mm x 120mm |
