| Place of Origin: | Shenzhen China |
|---|---|
| Brand Name: | VEGASHINE / OEM |
| Model Number: | IPPC215-T012311 |
| Minimum Order Quantity: | 1 unit |
| Packaging Details: | Carton |
| Delivery Time: | 3 to 10 work days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 units per Month |
| Material: | Aluminum Alloy | Screen: | 21.5 Inch Capacitive Touch Screen 16:9 |
|---|---|---|---|
| Brightness: | 400cd/m2 | Resolution: | 1920*1080 |
| CPU: | Celeron J1900 2GHz Quad-cores | Serial Ports: | 2* RS232 |
| RAM+ Storage: | 4GB + 64GB SSD | Waterproof And Dustproof: | IP65 |
| Highlight: | 64GB SSD Industrial Panel PC,21.5" Industrial Panel PC,J1900 All In One Kiosk PC |
||
21.5" Capacitive touch screen J1900 2 COM Tablet PC industry panel computer touch screen all in one kiosk PC, included 4GB RAM+ 64GB SSD DC power supply
Quick detail
Intel Celeron J1900 2GHz Quad-cores
4G DDR3 + 64G SSD
Screen size 21.5 inches
Resolution: 1920*1080
Capacitive touch screen
USB2.0*3+USB3.0*1
COM*2 RS232
WIFI*1
HDMI*1
VGA*1
RJ-45*1
12V 5A External power supply
Front panel IP65 dustproof and waterproof
Aluminum Alloy integral chassis fanless cooling
Working temperature : -20°C~70°C
Specifications
| General info |
Item No. | IPPC215-T012311 |
| Material | Aluminum Alloy | |
| Color | Black / Silver | |
| IP rating | IP65, indoor & outdoor complied | |
| Operation System | WIN 7/8/10/XP LINUX | |
| Weight | 5.7 KG | |
| Delivery time | 1-15 days depend on order quantity | |
| Warranty | 1 years | |
| Avalability of customization | YES | |
| Mainboard info |
CPU | Intel Celeron J1900 2GHz Quad-cores |
| HDD | 32G SSD | |
| RAM | 4G DDR3 | |
| Audio | Integrated audio chip | |
| Network | Integrated gigabit network card | |
| WIFI | Inner | |
| Graphics | Integrated | |
| System | WIN 7/8/10/XP LINUX | |
| Speaker | Inner | |
| Screen info |
Screen size | 21.5 inches |
| Resolution | 1920*1080 | |
| Proportion | 16:9 | |
| Gray-scale response time | 5ms | |
| Panel Type Industrial | Control A style TFT | |
| Point distance | 0.264mm | |
| Contrast | 1000:1 | |
| Backlight type | LED, lifespan≥50000h | |
| Display color | 16.7M | |
| Visual angle | 160 deg / 160 deg | |
| Brightness | 400cd/m2 | |
| Touch type | Default Capacitive (resistive and infrared optional) |
|
| Touches cycles | ≥ 50 million times | |
| Interface info |
USB | USB2.0*3+USB3.0*1 |
| Expansion | COM*2 | |
| Default protocol | RS232 | |
| WIFI | 1 PC | |
| Power Supply | DC12V *1 PC | |
| HDMI | 1 PC | |
| VGA | 1 PC | |
| Network card | RJ-45*1 PC | |
| Audio | Input *1 PC + output *1PC | |
| Other info |
Power Supply | 12V 5A External |
| Tablet Input voltage | 12V | |
| Anti-static | contact 4KV, air 8KV | |
| Monitor Power | ≤60W | |
| Anti-vibration | GB2423 standard in China | |
| Anti-interference | EMC & EMI anti-electromagnetic interference | |
| Dustproof and waterproof | front panel IP65 dustproof and waterproof | |
| Installation method | Default Embedded (desktop, wall-mounted, cantilever optional) |
|
| Ambient humidity | 5~85%, non-condensable | |
| Working temperature | -20°C~70°C | |
| Language menu | Chinese, English, German, French, Korean, Spanish, Italian, Russian,custumed |
Install
Embedded installation
Desktop installation
Wall mounted installation
VESA standing installation
Application
Factory automation
Internet of Things
Business intelligence terminal
Industrial production control
Industrial manufacture
Automatic control equipment
Kiosk
