Screen: | 12.1 Inch Capacitive Touch Screen | Color: | Black / Silver |
---|---|---|---|
Resolution: | 1280*800 | Waterproof And Dustproof: | IP65 |
CPU: | Intel J1900 2.0 GHz Quad-cores | Memory: | 4GB |
Storage: | 64GB SSD | Serial Ports: | 1* RS232 |
Highlight: | J1900 industrial panel computer,industrial panel computer IP65,industrial touch panel pc IP65 |
12.1 inch touch screen J1900 industrial panel computer IP65 waterproof all in one PC
Quick detail
Chassis material Aluminum Alloy
IP65 indoor & outdoor complied
Integrated Celeron® Bay Trail J1900 quad core 4 threads 2.0~2.42 Ghz processor
64G SSD
4G DDR3
Screen size 12.1 inches
Resolution: 1280*800
Capacitive touch screen
USB2.0*3+USB3.0*1
COM*1 RS232
WIFI*1
HDMI*1
VGA*1
RJ-45*1
12V 5A External power supply
Front panel IP65 dustproof and waterproof
Default Embedded install (desktop, wall-mounted, cantilever optional)
Working temperature : -20°C~70°C
Specifications
General info |
Item No. | IPPC121-T012311 |
Material | Aluminum Alloy | |
Color | Black / Silver | |
IP rating | IP65, indoor & outdoor complied | |
Operation System | WIN 7/8/10/XP LINUX | |
Weight | 2.8 KG | |
Delivery time | 1-15 days depend on order quantity | |
Certificate | CE ROHS | |
Warranty | 3 years | |
Avalability of customization | YES | |
Mainboard info |
CPU |
Integrated Celeron® Bay Trail J1900 quad core 4 threads 2.0~2.42 Ghz processor |
Hard disk | 64G SSD | |
Memory | 4G DDR3 | |
Audio | Integrated audio chip | |
Network | Integrated gigabit network card | |
WIFI | Inner | |
Graphics | Integrated | |
System | WIN 7/8/10/XP LINUX | |
Speaker | Inner | |
Screen info |
Screen size | 12.1 inches |
Resolution | 1280*800 | |
Proportion | 16:10 | |
Gray-scale response time | 5ms | |
Panel Type Industrial | Control A style TFT | |
Point distance | 0.264mm | |
Contrast | 1000:1 | |
Backlight type | LED, lifespan≥50000h | |
Display color | 16.7M | |
Visual angle | 160 deg / 160 deg | |
Brightness | 400cd/m2 | |
Touch type | Default Capacitive (resistive and infrared optional) |
|
Touches cycles | ≥ 50 million times | |
Interface info |
USB | USB2.0*3+USB3.0*1 |
Expansion | COM*1 | |
Default protocol | RS232 | |
WIFI | WIFI*1 | |
Power Supply | DC12V *1 | |
HDMI | HDMI*1 | |
VGA | VGA*1 | |
Network card | RJ-45*1 | |
Audio | Input *1 + output *1 | |
Other info |
Power Supply | 12V 5A External |
Tablet Input voltage | 12V | |
Anti-static | contact 4KV, air 8KV | |
Monitor Power | ≤60W | |
Anti-vibration | GB2423 standard in China | |
Anti-interference | EMC & EMI anti-electromagnetic interference | |
Dustproof and waterproof | front panel IP65 dustproof and waterproof | |
Installation method | Default Embedded (desktop, wall-mounted, cantilever optional) |
|
Ambient humidity | 5~85%, non-condensable | |
Working temperature | -20°C~70°C | |
Language menu | Chinese, English, German, French, Korean, Spanish, Italian, Russian,custumed |
About RMA
1--Warranty 1 year
2--If buyer confirm the item can`t work well due to the non-artificial factors,buyer can return it to our company. Buyers should keep it with proper packaging.
3--Buyers are responsible for return to china freight cost .
4--Seller will repair item and ship the repaired one to buyer,seller will pay the shipping cost from China to Buyer address.
5--Please contact us firstly before returning defective goods by email.
Shipping
Support DHL / UPS / FEDEX / air shipping deliver time 4 to 9 business days
Support Sea shipping for Batch order deliver time 25 to 45 days
