| Place of Origin: | Shenzhen China |
|---|---|
| Brand Name: | VEGASHINE / OEM |
| Model Number: | OPS-PM07-I5 |
| Minimum Order Quantity: | 1 unit |
| Packaging Details: | Carton |
| Delivery Time: | 3 to 10 work days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 units per Month |
| CPU: | Kaby Lake I5-7200U Dual Cores 4 Threads 2.5~3.1Ghz | RAM: | 1*DDR4 SODIMM 260 Socket |
|---|---|---|---|
| Ethernet: | 1*Gigabit LAN | Display: | VGA / HDMI |
| COM: | 1* RS232 | NGFF_SSD: | 1*NGFF_SSD Port |
| Power: | Single Input DC Power Supply, DC12-19V | Size: | 165*114.2 Mm |
| Highlight: | 7th kaby lake motherboard,I5-7200U kaby lake motherboard,7th intel kaby lake motherboard |
||
DC12-19V Intel 7th Mobile Kaby lake-U i5-7200U OPS motherboard with1*RS-232 NGFF_SSD for Electronic Whiteboard
Key features
Integrated Kaby Lake i5-7200U dual cores 4 threads 2.5~3.1Ghz
Support 1 *DDR4 SODIMM 260 Socket
Onboard 1*Gigabit Ethernet Port
1*SATA3.0
1*NGFF_SSD Port
1*Gigabit LAN
1*HDMI
1*VGA
2*USB3.0
4*USB2.0
Size: 165*114.2 mm
Specifications
| Processor | CPU |
Integrated Kaby Lake i5-7200U dual cores 4 threads 2.5~3.1Ghz Max Turbo Frequency 3.1Ghz |
| CPU package | BGA | |
| chipset | Intel Kaby lake-U serial CPU | |
| BIOS | EFI BIOS | |
| Memory | Technology Architecture | Single channel DDR4 2133MHz |
| socket | 1 *DDR4 SODIMM 260 Socket | |
| Video | Graphic controller | Intel HD Graphics 620(I3-7100U graphics card); graphics models related to CPU |
| VGA | VGA support max resolution:2048x1536 | |
| HDMI | support max resolution(HDMI1.4)4096*2304@30HZ support 4k display output | |
| Dual display | HDMI+VGA sync or asynchronous display | |
| I/O back panel | Port | 1*VGA,1*HDMI,1*LAN,2*USB3.0/,4*USB2.0,1*MIC-OUT/LINE-OUT, 1 * Power indicator, 1 * Hard disk indicator 1 * , 1 * restart button |
| Internet | controller | 1 * RTL8111E-V Gigabit Ethernet, RJ45 interface |
| Audio | controller | Realtek HD ALC662 audio decoding (left and right channel + microphone) |
| Super I/O | controller | IT8163E |
| Hardware control | Watchdog timer | 0-255 seconds to provide watchdog routines |
| Cooler | Aluminum fan heatsink | |
| Input / output interface | USB |
2*USB3.0 compatible with USB2.0 / 1.1,max support +5V/1A 4*USB2.0 |
| COM | 1*RS-232 | |
| Expansion bus | NGFF | 1*NGFF Port(KEY E) |
| NGFF | 1*NGFF port , support 3G/4G Module | |
| storage | SATA | 1 standard SATAIII interface, maximum transfer rate of 6Gb/s (and SATA_HDD one by one, default is SATA_HDD) |
| SATA_HDD | 1*SATA_HDD hard disk interface, maximum transfer rate of 6Gb/s (and SATA two) | |
| NGFF | 1*NGFF_SSD Port | |
| Power type | Power type | Single input DC power supply,DC12-19V,+/-5% |
| Power consumption | 35W | |
| Working temperature | Working temperature | -20℃ ~ +60℃ |
| Storage temperature | -40℃ ~ +85℃ | |
| Operating humidity | 0% to 90% relative humidity, no condensation | |
| Storage humidity | 0% to 90% relative humidity, no condensation | |
| size | size | 165*114.2 mm |
| weight | 0.5KG |
Application
Teaching whiteboard / Education electronic whiteboard / Classroom interactive whiteboard
Meeting interactive whiteboard / Coference interactive whiteboard
Shipping
Support DHL / UPS / FEDEX / air shipping deliver time 4 to 9 business days
Support Sea shipping for Batch order deliver time 25 to 50 days
